ZLA-25L Semi-automatic Auger filling machine
Descriptive abstract
This type can do dosing and filling work. Due to the special professional design, so it is suitable to the fluidic or low-fluidity materials, like coffee powder, wheat flour, condiment, solid drink, veterinary drugs, dextrose, pharmaceuticals, powder additive, talcum powder, agriculture pesticide, dyestuff, and so on.
主な特徴
Stainless steel structure；Quick disconnecting or split hopper could be washed easily without tools.
Servo motor drive screw.
PLC & touch screen make it be easy of operation.
重量のフィードバックと比例のトラックは、異なる材料の様々な割合のための可変包装重量の不足を取り除く。
Save the parameter of different filling weight for different materials. To save 10 sets at most
Replacing the auger parts, it is suitable for material from super thin powder to granule.
Main Technical Data
| Hopper | Quick disconnecting hopper 25L |
| パッキング重量 | 10 - 1000g |
| パッキング精度 | ≤ 100g,≤±2%; 100 – 500g, ≤±1%; ≥500g,≤±0.5% |
| 充填速度 | 5 – 20 times per min |
| 電源 | 3P AC208-415V 50/60Hz |
| トータルパワー | 2.25Kw |
| 総重量 | 350kg |
| Overall Dimensions | 1205×1010×2174mm |
